DCR Red Conformal Coating

In Stock

DCR is a specialist red conformal coating, designed to conceal the PCB design while offering excellent protection. Based on a Modified Alkyd it has been formulated to meet the highest defence standards in both Europe and the United States and is also resistant to many solvents used in the aerospace and automotive industries. DCR can be sprayed, dipped or brushed, for full product details including test results please refer to the TDS below. If you still require further information please don’t hesitate to get in touch.


Approvals RoHS Compliant (2015/863/EU): Yes
IPC-CC-830: Meets approval
UL746C-QMJU2: Meets approval
Liquid Properties Appearance: Red Opaque
Density @ 20°C (g/ml): 1.08 (Bulk), 0.78 (Aerosol)
VOC Content: 40% Bulk, 61% Aerosol
Flash Point: 27°C (Bulk) <23°C (Aerosol)
Solids content: 60% (Bulk) 39% (Aerosol)
Viscosity @ 20°C (mPa s): 410 – 650 (Bulk)
Touch Dry: 50 – 55 minutes
Recommended Curing Schedule*: 2 Hours @ 20°C followed by:
2 – 24 Hours @ 90°C to 120°C
*(Maximum Solvent Resistance Achieved @ 120°C; Ambient Curing Schedule: 24 Hours @ 20-25°C)
Coverage @ 25µm: 24m2 per litre (Bulk), 3m
2 (200ml Aerosol)
Cured Film Coating Colour: Red Opaque
Operating Temperature Range: -70°C to +200°C
Flammability: Meets UL94 V-1
Thermal Cycling (MIL-1-46058C): Meets approval
Coefficient of Expansion: 85ppm
Dielectric Strength: 90 kV/mm
Dielectric Constant: 4.75 @ 1MHz
Surface Insulation Resistance: 1 x 1015 Ω
Dissipation Factor (@ 1MHz, 25°C): 0.044
Moisture Resistance (MIL-1-46058C): Meets approval
